LYK8-08A (standard）/LYK8_08A-H(high-end）
Pneumatic Marking Control System: LYK8-08A(H)
Parameters
CPU: Embedded 4-core Cortex-A9, maximum frequency 1.6GHz
RAM: 1GB,DDR3
Solid State Storage FLASH: 8GB EMMC SSD (on-board soldering, non-pluggable)
Display Size: 8 inches
Display Resolution: 1024* 768
Touch Screen Type: Resistive screen
USB: 3
Ethernet: 1
Serial Port: 2
Drive Port: X,Y,Z three-axis pulse control
Expansion IO: LYK8-08A 3 inputs, 2 outputs, LYK8-08A-H 8 inputs, 8 outputs
Click to download:
LYK8-08A(H) hardware user's manual
